24路高清编码器

区域: 四川成都市

总量: 10000 件

期限: 自买家付款之日起 3 天内发货

参数: 品牌德芯8路高清编码器8 hdmi116路高清编码器16 hdmi

成都德芯数字科技股份有限公司

成都德芯数字科技股份有限公司

进店

店铺主推
最新发布

产品详情

24路高清编码器 16路高清编码器 8路高清编码器

l Support 2/4/8//16/24 HDMI inputs, with2/4/ 8/16/24 SPTS output (each encoder module, only support STPS, NO MPTS), max 24 HDMI inputs

l MPEG4 AVC/H.264/H265 video encoding format

l MPEG1 Layer II, LC-AAC，HE-AAC audio encoding format and AC3 Pass Through, and audio gain adjustment

l Support IP Output over UDP (Unicast/Multicast), SRT, RTSP, RTP, RTMP, HTTP, HLS, M3U8

l Support QR code, LOGO, caption insertion (Language Supported: 中文, English, العربية, ไทย, हिन्दी, руская, اردو for more languages please consult us…)

l Support “Null PKT Filter” function

l Control via web management, and easy updates via web

HDMI Encoding Section
Video	Encoding	HEVC/ H.265 , MPEG 4 AVC/H.264
	Interface	2/4/8/16/24 HDMI input
	Resolution	19201080_60P, 19201080_50P; 19201080_59.94P, 1280720_60p, 1280720_59.94 1280720_50P
	Chroma	4:2:0
	Bitrate	1Mbps~15Mbps
	Rate Control	CBR/VBR
	GOP Structure	IP
Audio	Encoding Format	MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2; AC3 Pass-through
	Sample rate	32KHz,44.1KHz,48KHz
	Bit-rate	48~384Kbps

Stream output	IP out over UDP (Unicast/Multicast),RTP/M3U8/SRT, RTP,RTSP, RTMP, HTTP, HLS (RJ45, 1000M ) (8 HDMI inputs with 8 SPTS for each encoder board)
System function	Network management(WEB)
	Chinese and English language
	Ethernet software upgrade
Miscellaneous	Dimension (W×L×H)	482mm×328mm×44mm
	Environment	0~45℃(work)；-20~80℃（Storage）
	Power requirements	AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz
